🚀 Application Development Kit 🚀

This is an easy-to-use application starter kit. The workflows from creating a new application, doing development, and managing dev, stage, and prod environments are included.

Note

Why another Docker based workflow? Two reasons:

• 👉 Template Based - I want to be able to use the same kit for many different frameworks. So no matter if you are developing in Laravel or Django or just need to spin up a quick MySQL data server, there are templates to support your needs.
• 👉 Enhanced Environment - The template provides the initial infrastructure as code. If needed, you can modify the image to add new features. For example, I had a need to integrate with SQL Server, Active Directory, and other services, so a quick modification of the Dockerfile got me where I needed to be.
• 👉 Architecture - I believe that the code for the CI/CD or DevOps tooling does not belong in the same git repo as your application code.
• 👉 Deployments - The deployment pipeline should leverage infrastructure as code and be easy. This kit makes it easy to deploy your changes to any number of servers.

‼️ Getting Started

Here is getting started video using the Laravel template. The other templates follow the same pattern.

1️⃣ Installation

Docker Environment

To get started, make sure you have Docker installed on your system.

Install the kit

Setup directory structure and clone this repo:

1. mkdir project
2. cd projects
3. git clone https://github.com/rcravens/kit.git --config core.autocrlf=false infra
4. cd infra
5. ./.code/bin/install.sh ‼️ this creates a kit alias that you can use ‼️

2️⃣ ️Create Development Environment

Development environments are created using a template to scaffold both infrastructure code and application code. kit new will list out all the available templates. For example to create a Laravel development environment:

• kit new laravel and answer the on-screen questions....that's it!

Important

The kit new laravel command will do all the following automatically:

1. Create code directory named projects/code/<APP NAME>
2. Clone the git repo into the code directory
3. Create a .env in the code directory for the Laravel application. Many of the values are updated based on the .env in the docker settings
4. Build the Docker images.
5. composer install to install PHP dependencies
6. php artisan key:generate to create the app key
7. php artisan migrate to run the initial migrations
8. npm install to install the Node dependencies
9. npm run build to build the front-end assets
10. Insert domain in /etc/hosts file
11. kit open to open up a browser tab to the application

Using kit new <template> will quickly create a development environment on your local machine. There you can make changes to the application code or changes to the infrastructure code.

kit new - Will list out the currently available templates. Here are a few of the supported technology stacks:

• Django (kit new django) - Read the templates/django/README.md for more details about this template.
• FastApi (kit new fastapi) - Read the templates/fastapi/README.md for more details about this template.
• Flask (kit new flask) - Read the templates/flask/README.md for more details about this template.
• Laravel (kit new laravel) - Read the templates/laravel/README.md for more details about this template.
• MySQL (kit new mysql) - Read the templates/mysql/README.md for more details about this template.
• PostgreSQL (kit new postresql) - Read the templates/postresql/README.md for more details about this template.
• Redis (kit new redis) - Read the templates/redis/README.md for more details about this template.

Not seeing what you want? There is a templates/.empty example that you can use to create a new technology stack. Checkout the templates/.empty/README.md file for details on how to create your own.

3️⃣ Provision Servers

Provisioning infrastructure for deployments should be easy and repeatable. The templates provide "infrastructure as code" that you can use to provision servers. Need multiple environments? No problem! Just repeat the process below for your stage, test, prod, or other environments.

Note

Under the hood, this kit use the following technologies:

• Docker to containerize your application. Each application uses a multi-stage build so that both the dev and prod environments sit on the same "base image".
• Docker Swarm to deploy your application across a number of nodes. This makes for easy zero-downtime deployments that you can scale to meet demand.
• Ansible as a configuration management tool to ensure your nodes have the right packages and configurations required.

Follow these steps to create a server environment:

1. Run kit make server <name> where <name> is the destination name (e.g., prod, stage, test). This will scaffold in the files needed to provision the Docker Swarm server. In the resulting directory:
   1. Update the swarm_settings.yml file with the following information:
      1. ___AWS_ACCOUNT_ID___ - the Amazon AWS account where the infrastructure will be provisioned.
      2. ___PREFIX___ - the prefix used in all the infrastructure component names.
      3. ___DOMAIN___ and ___SUB_DOMAIN___ - the domain and sub-domain to set up DNS records for. Your app will be available at https://SUB_DOMAIN.DOMAIN
      4. num_worker_nodes - update this number to the desired number of worker nodes.
      5. is_mysql_needed - update this flag if MySQL is needed. If this flag is yes then an RDS - MySQL variant will be provisioned. Scroll down to the RDS section and complete the configuration of db name, user, and passwords.
      6. is_redis_needed - update this flag if Redis is needed. If this flag is yes then an Elasticahce - Redis variant will be provisioned.
      7. cidr_first_two_octets - Set the first to octets of the CIDR block. This helps to avoid collisions if you are deploying multiple swarms.
2. Run kit provision <name> command. This runs an Ansible playbook that provisions the infrastructure, and configures your Docker Swarm.

After the above completes, you should have a cloud architecture where you can deploy your application. Repeat the above steps to create destinations for all your desired environments (e.g., test, stage, prod).

4️⃣ Deployments

First we need to configure a Docker container registry for our application.

1. Run kit <app> make registry answer the on-screen questions and you are done!

Now the deployment process is super easy:

1. Run kit <app> image to build a new production ready Docker image.
2. Run kit <app> push <tag> to tag and push the image to the configured container registry.
3. Run kit <app:srv> deploy where <srv> is one of the servers you set up. This will deploy your application to that server.

5️⃣ Shell Access and Running Remote Commands

To get shell access run the following:

kit <app:srv> ssh <ip>

• app is the application
• srv is the external server
• ip is an optional IP address in the external server Docker Swarm

Either app or srv should be specified. Examples:

• kit laravel ssh gets shell access inside the local laravel application
• kit :prod ssh gets shell access inside the manager node of the prod Docker Swarm
• kit :prod ssh 10.0.1.48 gets shell access inside 10.0.1.48 node of the prod Docker Swarm

To run a remote command for an application execute the following:

kit <app:srv> run <cmd>

This will create a new container using the <app> image on the manager node of the <srv> Docker Swarm. Then it will execute <cmd> inside this new container. Once execution completes, the container is destroyed. Examples:

• kit laravel:prod run php artisan migrate runs php artisan migrate in a container on the manager node of the prod Docker Swarm. The container is created from the laravel image.
• kit laravel:prod run "php artisan horizon &" starts Laravel Horizon in a container on the manager node of the prod Docker Swarm. The container is created from the laravel image.
• kit laravel:prod run "crond -f

General Information (WIP)

📁 Directory Structure

If you followed the Quick Start above you will find the following directory structure (skipping some details for clarity):

• projects: This is the main directory that holds all the files
  • code: When you kit new <template> the application code is created here. This is where you go and edit your code. Each application will be in its own subdirectory.
  • infra: This directory holds all the "kit code and templates"
    • .code: Kit code. You should not change any files in this directory. Changes will be lost when you git pull.
    • .code/bin: Kit shells scripts. You should not change these. Changes will be lost when you git pull.
    • .code/templates: Kit templates. You should not change these. You are welcome to create your own and submit pull requests. Would love to build the ecosystem.
    • apps: When you kit new <template>, the infrastructure code is copied into here. One subdirectory per application. This allows you to alter or fine tune the infrastructure code.
    • servers: When you kit make server <name> your new server environment will be created here.
    • kit: This is the main kit shell script. Entry point for all kit commands.

💥 Commands

Commands have the following format: kit <app:srv> <command> <arguments>

• <app:srv> is the application name and the deployment server.
  • This kit allows you to create many apps under one directory. Defaults to the app corresponding to the first child directory in ./apps.
  • The :srv part is optional. If not specified, then the command is applied to the local dev environment. Some commands can be run on a remote server by specifying the :srv option. The :srv option needs to match the name of an existing server that was created using the kit make server <name> command.
• <command> is the command to be run. This kit has a number of "base" commands (e.g., deploy, destroy, down,...) that provide base functionality. Once you create an application using the kit new <template> command, then each application can provide additional commands (e.g., laravel applications have artisan add-on commands).
• Depending on the <command>, actions will be taken either on the dev or prod environments. The following files are used automatically when running commands that envoke Docker:

env	files
dev	docker-compose.yml, dev/docker-compose.yml and dev/.env
prod	docker-compose.yml, prod/docker-compose.yml and prod/.env

Note

The biggest difference between the dev and prod environments is where the application code exits:

• dev environments have the code mounted into the image using a volume. This allows you to make code changes and those dynamically appear in the browser.
• prod environments have the code "baked into the image" using a add statement. This creates a fully functioning containerized environment that can be pushed to a container registry and deployed to production or other servers.

• <arguments> are arguments expected by the command. For example, kit new laravel the new command takes as an argument the template name, this case laravel.

💡 Templates

Template Structure

Each technology stack is created using the kit new <template> command. Each template has all the files necessary to create both the initial application code (based on a repo or a default starter project) and the infrastructure code. Templates require the following files:

• bin directory to hold all the scripts / executables for the template
  • init.sh (optional) a custom initialization script that is run early in the kit new command. This allows the template to gather data and create the env.dev and env.prod environments.
  • create.sh a custom creations script that is run later in the kit new command. This allows the creation of the initial application code.
  • set_env.sh this is a script that sets any custom environment variables. it is run when any commands are executed for applications created with this template.
  • commands directory to hold all custom commands that are introduced by the template
    • build.sh a custom build script for the application code. What ever your application requires when it needs to be build can be put in here.
• envs directory to hold directories for each supported environment
  • .env.template a template file that generates user prompts and is transformed int .env files for each environment directory
  • dev directory to hold all files related to the dev environment
    • .env environment file for Docker Compose. This file is generated by transforming .env.template
    • docker-compose.yml (optional) overrides file for Docker Compose
  • prod directory to hold all files related to the prod environment
    • .env environment file for Docker Compose. This file is generated by transforming .env.template
    • docker-compose.yml (optional) overrides file for Docker Compose
• deploy_settings.yml this data is updated as part of the kit <app> make registry command and has settings relevant to deployments.
• docker-compose.yml the base compose file used by Docker
• Dockerfile a multi-stage build that allows a dev and prod target
• README.md specific information about the template

Create Your Own Template?

Yes, please! Would love to integrate additional templates for the community to use with this kit platform.

Just follow the instructions in the templates/.empty/README.md file to create your own template.

Let me know if you have any issues!

Once you have a working template, create a pull request and I can merge it in!

💥 Older Videos

Note

I am keeping these here as they may still be useful. This kit has morphed from being a "dedicated" laravel kit, to leveraging templates to support any technology stack. It has also evolved from just supporting a local development environment to providing a more complete workflow that includes deployment. So the following videos may provide some additional value, the exact commands shown might not match the current kit.
